7417 Hex Buffer High Voltage Open Collector IC (DIP)

Availability:

In stock


– Six independent buffer/inverter gates in one DIP-14 package
– Open-collector outputs for direct connection to higher-voltage loads
– High output voltage tolerance up to 30V with 40 mA sink current
– TTL-compatible inputs for easy interfacing with 5V logic
– Ideal for driving LEDs, relays, solenoids and transistor stages
– Fast switching (typical 10 ns) with low power consumption
– Great for prototyping on breadboards, PCBs and educational projects

WhatsAppChat on WhatsApp

₨ 40

In stock

Factory tested, sent sealed Film your unboxing so we can quickly replace anything damaged, missing or wrong. Returns, refunds and warranty

7417 Hex Buffer High Voltage Open Collector IC (DIP)

The 7417 is a robust hex buffer/inverter IC from the 74xx TTL family that combines six independent gates with open-collector outputs and high-voltage tolerance. Designed for reliable signal buffering, current driving, and logic level shifting, this DIP-14 device is ideal for hobbyists, students, and industry designers who need to interface 5V TTL logic with higher-voltage external loads.

Key Benefits

  • Drive higher-voltage devices directly using open-collector outputs and external pull-up resistors.
  • Buffer and strengthen digital signals for long traces or noisy environments.
  • Perform TTL-to-higher-voltage level shifting without complex circuits.
  • Suitable for direct driving of LEDs, relays and transistor stages, reducing component count.

Features

  • Six independent buffer/inverter gates in one IC (hex configuration).
  • Open-collector outputs for flexible pull-up voltage selection (up to 30V).
  • TTL-compatible input thresholds for seamless 5V logic integration.
  • Maximum output sink current: 40 mA per gate for driving moderate loads.
  • Typical propagation delay: 10 ns for fast switching performance.
  • Standard DIP-14 package for easy breadboard and PCB use.
  • Low quiescent power consumption for efficient operation.

Specifications

  • IC Number: 7417
  • Logic Type: Hex buffer/inverter with open-collector outputs
  • Number of Gates: 6
  • Inputs per Gate: 1
  • Operating Voltage (Vcc): 4.75V to 5.25V (typical 5V)
  • Maximum Output Voltage (open-collector): 30V
  • Output Current (Low, sink): 40 mA (max)
  • Input Current (High): 40 µA (max)
  • Input Current (Low): -1.6 mA (max)
  • Propagation Delay: 10 ns (typical)
  • Package Type: DIP-14 (Dual Inline Package)
  • Operating Temperature Range: 0°C to +70°C

Typical Applications

  • Logic level shifting between TTL logic and higher-voltage devices.
  • Driving LEDs, relays, solenoids and transistor inputs directly.
  • Digital signal buffering and conditioning for pulse or clock lines.
  • Interfacing microcontrollers and logic ICs with external high-voltage loads.
  • Educational circuits, prototyping and industrial control interfaces.

Usage Notes and Best Practices

  • Because outputs are open-collector, use an appropriate external pull-up resistor to the desired pull-up voltage (max 30V).
  • Observe the maximum sink current (40 mA) per output to avoid thermal stress; distribute loads when driving multiple outputs simultaneously.
  • Keep Vcc at a stable 5V supply for proper TTL input thresholds and predictable timing characteristics.
  • When driving inductive loads such as relays or solenoids, include flyback diodes or snubber circuits to protect the IC and other system components.
  • For breadboard prototyping, the DIP-14 package allows quick swaps; consider a socket to prevent repeated solder cycles.

Typical Connection Example

Connect Vcc to 5V and GND to ground. For each output that must drive a higher-voltage load, connect the load between the chosen pull-up voltage and the output pin, and fit a suitable pull-up resistor. Use flyback protection for inductive loads and ensure the total current per package stays within safe limits.

Why Choose the 7417?

The 7417 Hex Buffer provides a simple, reliable way to combine TTL logic compatibility with the ability to switch higher voltages and moderate currents. Its open-collector outputs and DIP-14 footprint make it a versatile component for prototyping, education and practical control applications where level translation and direct drive are required.
