The 1S–8S Lithium Battery Capacity Level Indicator Module is a compact and efficient battery monitoring device designed to display the real-time charge level of lithium battery packs. It supports 1S to 8S lithium batteries, making it suitable for a wide range of battery configurations used in robotics, DIY electronics, electric vehicles, and portable power systems. The module features LED indicators for quick and easy battery status monitoring.
Key Features
- Wide Battery Support: Compatible with 1S to 8S lithium battery packs (3.7V to 29.6V).
- LED Level Display: Multiple LED indicators show battery charge level clearly.
- Real-Time Monitoring: Instantly displays remaining battery capacity when connected.
- Compact Design: Small size for easy installation in battery-powered projects.
- Low Power Consumption: Minimal power draw ensures efficient operation.
Technical Specifications
- Product Type: Battery Capacity Indicator Module
- Supported Batteries: Lithium-ion / Lithium polymer (1S–8S)
- Input Voltage Range: Approx. 3V – 34V
- Display Type: LED Level Indicator
- Connection Type: Positive (+) and Negative (–) terminals
- Size: Compact module (may vary by model)
- Mounting: Through-hole / panel mount (model dependent)
Applications
- Lithium battery packs monitoring
- DIY power banks and portable devices
- Robotics and RC battery systems
- Solar energy storage systems
- Electric bicycles and scooters
- Battery-powered electronics projects
Advantages
- Quick and easy battery level indication
- Supports multiple battery configurations
- Simple wiring and installation
- Reliable and reusable monitoring module
Safety & Usage Notes
- Ensure correct polarity before connecting.
- Use within specified voltage range only.
- Avoid short-circuiting battery terminals during installation.
Note: Images are for Illustration Purposes Only. Actual product design, LED layout, and appearance may vary slightly.
How do I connect a 1S-8S lithium battery indicator?
Connect the module’s positive (+) terminal to the battery pack’s positive wire and the negative ( – ) terminal to the negative wire. The LED bar lights up to show the charge level. Always check polarity before powering up.
For a permanent install, you can mount the module through a panel or use the through-holes. Keep wires short and secure. If you are building a pack, pair it with a Li-ion Lithium Battery Charging Protection Module Type-C (TP4056) for safe charging.
This indicator works with 1S to 8S lithium-ion or lithium polymer packs, covering roughly 3.7V to 29.6V. It draws very little power, so it can stay connected without draining the battery quickly.
What should I check before buying a battery level indicator?
First, count your battery cells in series (S). This module supports 1S to 8S, so it fits most common packs used in RC, robotics and solar projects. Second, confirm your pack voltage stays within the module’s input range of about 3V to 34V. Third, decide how you will mount it: through-hole or panel mount, depending on the model.
Installation is simple: two wires, positive and negative. No programming needed. The LED display gives an instant readout, which is handy for quick checks in the field.
Warranty and delivery: College Road Electronics is based in Rawalpindi and delivers nationwide across Pakistan with flat-rate shipping of Rs 350. For warranty details, contact the shop directly. Prices for this module were checked in September 2026 and start at Rs. 230.
Frequently Asked Questions
What does 1S-8S mean on a lithium battery indicator?
1S-8S means the module works with lithium battery packs that have 1 to 8 cells connected in series. A 1S pack is a single cell (about 3.7V nominal), while an 8S pack is eight cells in series (about 29.6V nominal). The indicator automatically adjusts to show the level for the connected pack.
Can I use this indicator with a 3S or 4S LiPo battery?
Yes. The module supports any pack from 1S to 8S, including common 3S and 4S LiPo batteries used in RC cars and drones. Just connect the positive and negative terminals to the pack’s main leads. The LED display will show the approximate charge level.
How do I install the 1S-8S lithium battery indicator?
Solder or connect the module’s positive (+) terminal to the battery positive and the negative ( – ) terminal to battery negative. Mount it through a panel or using the through-holes if you want a permanent install. No programming is required. Always double-check polarity before applying power.
What is the price and delivery time for this module?
The 1S-8S Lithium Battery Capacity Level Indicator Module is priced at Rs. 230 as checked in September 2026. College Road Electronics delivers nationwide across Pakistan with flat-rate shipping of Rs 350. Delivery time depends on your location; contact the shop for an estimate.
Does this battery indicator work with a solar panel setup?
Yes, it can monitor the battery bank in a solar energy storage system as long as the pack is within 1S to 8S and the voltage stays within the module’s range. It shows the charge level, helping you track when the battery needs charging. It does not control charging or discharging by itself.
