UNI-T UT204+ Professional Digital Clamp Meter Multimeter

UNI-T UT204+ Professional Digital Clamp Meter Overview

The UNI-T UT204+ is a professional-grade digital clamp meter multimeter designed for technicians and electricians who need accurate, reliable measurements in the field or workshop. It combines flexible current clamping with comprehensive multimeter functions to test AC/DC current, voltage, resistance, capacitance, frequency and temperature.

Key Features

• Dual AC and DC current measurement: 60A and 600A ranges with ±(2.5%+5) accuracy.
• Wide voltage coverage: AC (6V / 60V / 600V) and DC (600mV / 6V / 60V / 600V) with high precision.
• Comprehensive resistance and capacitance ranges for electronics and electrical troubleshooting.
• Temperature support from -40°C to 1000°C for HVAC and industrial applications.
• Frequency measurement up to 10MHz and AC voltage frequency up to 60kHz for advanced diagnostics.

Technical Specifications

• AC Current (A): 60A / 600A, Accuracy ±(2.5%+5)
• DC Current (A): 60A / 600A, Accuracy ±(2.5%+5)
• AC Voltage (V): 6V / 60V / 600V, Accuracy ±(0.8%+5)
• AC Voltage Frequency (V): 10Hz to 60kHz, Accuracy ±(0.5%+2)
• DC Voltage (V): 600mV / 6V / 60V / 600V, Accuracy ±(0.5%+2)
• Resistance (Ω): 600Ω / 6kΩ / 60kΩ / 600kΩ / 6MΩ / 60MΩ, Accuracy ±(0.8%+2)
• Capacitance (F): 6nF / 60nF / 600nF / 6µF / 60µF / 600µF / 6mF / 60mF, Accuracy ±(4%+5)
• Temperature (°C): -40°C to 1000°C, Accuracy ±(1.5%+5)
• Frequency (Hz): 10Hz to 10MHz

Who Should Use the UNI-T UT204+

This clamp meter is ideal for professional electricians, HVAC technicians, maintenance engineers and electronics technicians who require a reliable multimeter with clamp current capability and broad measurement ranges.

Typical Applications

• AC and DC current diagnostics on residential, commercial and automotive systems
• Voltage and resistance checks for circuit troubleshooting
• Capacitance and frequency testing for electronic components and filters
• Temperature measurements for HVAC, motors and industrial equipment

What You Get

• UNI-T UT204+ clamp meter multimeter
• User manual and safety information
• Test leads and accessories (as specified by your retailer)

For reliable, accurate electrical diagnostics in demanding environments, the UNI-T UT204+ Professional Digital Clamp Meter offers the essential functions and ranges professionals depend on.
