Pixhawk 2.4.8 Flight Controller Kit

Pixhawk 2.4.8 Flight Controller Kit Overview

The Pixhawk 2.4.8 Flight Controller Kit is a versatile, open-source flight control solution engineered for hobbyist and professional UAV, drone, and robotics projects. Combining a powerful STM32F427 processor with a robust IMU and multiple communication interfaces, the Pixhawk 2.4.8 delivers stable flight control, autonomous waypoint navigation, and easy integration with cameras, gimbals, and telemetry systems.

Why choose the Pixhawk 2.4.8 Flight Controller Kit

• Open-source hardware and firmware compatibility with ArduPilot and PX4 for flexible customization and community support.
• Accurate navigation and attitude estimation through an MPU6000 IMU and HMC5883L magnetometer.
• Comprehensive I/O including I2C, UART, CAN, and up to 8 PWM outputs for motors and servos.
• Supports GPS waypoint missions, telemetry monitoring, and failsafe features for safer autonomous flights.

Key Features

• Advanced Flight Control: Precise stabilization and control for multi-rotor, fixed-wing, and hybrid airframes.
• Open-Source Firmware: Full compatibility with ArduPilot and PX4 for mission planning and custom firmware development.
• Multi-Sensor Integration: MPU6000 gyroscope and accelerometer plus HMC5883L magnetometer for reliable attitude and heading reference.
• GPS Waypoint Navigation: Autonomous mission planning via GPS modules using UART or I2C connections.
• High Processing Power: STM32F427 ARM Cortex M4 delivers real-time control and fast sensor fusion.
• Versatile Communication: Multiple I2C, UART, CAN, and PWM ports plus 3DR telemetry compatibility (433MHz or 915MHz).
• Failsafe & Redundancy: Built-in failsafe protocols to protect the aircraft during critical events.
• Expandable System: Supports add-ons like GPS modules, cameras, gimbals, rangefinders, and companion computers.

Technical Specifications

• Processor: STM32F427 ARM Cortex M4
• IMU: MPU6000 gyroscope and accelerometer
• Compass: HMC5883L magnetometer
• GPS Interface: UART or I2C compatible
• PWM Outputs: Up to 8 PWM outputs for motors and servos
• I/O Ports: Multiple I2C, UART, CAN interfaces
• Telemetry: 3DR Telemetry compatible (433MHz or 915MHz)
• Input Voltage: 5V DC
• Firmware: Compatible with ArduPilot and PX4
• Form Factor: Compact, lightweight design to fit most UAV frames

Compatibility and Expandability

• Works with most GPS modules, 3DR telemetry radios, ESCs, servos, cameras, and gimbals.
• Supports companion computers and external sensors via UART, I2C, and CAN for advanced autonomy and computer vision.
• Open-source firmware allows integrations with third-party ground stations and mission planners.

Applications

• Multi-rotor, fixed-wing, and VTOL drone control
• Aerial photography, surveying, and mapping with stabilized camera systems
• Industrial inspection, agriculture, and delivery UAVs
• Robotics research, education, and custom DIY UAV projects

Installation and Setup Tips

• Mount the controller on vibration-damping material and keep the compass away from high-current wiring and motors.
• Use the latest ArduPilot or PX4 firmware and follow calibration procedures for accelerometer, compass, and radio control.
• Verify failsafe, battery monitoring, and telemetry links before first flight.
• Start with conservative PID and flight parameters, then tune gradually for your frame and payload.

Package Includes

• 1x Pixhawk 2.4.8 Flight Controller
• 1x Pixhawk 2.4.8 GPS Module
• 1x Power Distribution Board
• 1x Telemetry Radio Set
• 1x Cables and Connectors Kit

Frequently Asked Questions

• Is the Pixhawk 2.4.8 compatible with ArduPilot and PX4? Yes. The hardware is widely supported by both ArduPilot and PX4 ecosystems.
• Can I add a camera gimbal? Yes. The controller supports camera and gimbal control via PWM or auxiliary outputs and integrates with mission planners for camera triggers.
• What telemetry options are supported? It is compatible with 3DR telemetry radios (433MHz or 915MHz) and other serial telemetry devices over UART.

Note: Images are for illustration purposes only.
