Metal Film Resistors (5% 1/4 Watt) (Small Values)


  • High Precision: 1% tolerance ensures accurate resistance values for precision circuits.
  • Stable Performance: Reliable under various environmental conditions.
  • Wide Range: Small resistance values from 1Ω to 150Ω available.
  • Compact Design: Space-saving form factor for densely packed circuit boards.
  • Durable: High-quality materials withstand thermal and mechanical stress.
  • RoHS Compliant: Free from hazardous substances, meeting environmental standards.
  • Versatile Applications: Ideal for instrumentation, analog circuits, voltage dividers, current sensing, and calibration.

2.00

Overview

Discover the precision and reliability of our 1% Tolerance Small Value Resistors, designed for applications requiring high accuracy and stable performance. These resistors, available in an array of small resistance values, are ideal for fine-tuning circuits, ensuring minimal deviation from specified resistance values, and maintaining consistent performance in sensitive electronic applications.

Key Features

  • High Precision: With a tight tolerance of 1%, these resistors ensure accurate resistance values, making them perfect for precision circuits.
  • Stable Performance: Designed to maintain their resistance value over time and under various environmental conditions, these resistors provide reliable performance in all scenarios.
  • Variety of Values: Available in a wide range of small resistance values, allowing for fine-tuning and precise adjustments in your circuits.
  • Compact Design: Their small form factor makes them suitable for densely packed circuit boards, saving space without compromising performance.
  • Durability: Built with high-quality materials, these resistors are designed to withstand thermal and mechanical stress, ensuring longevity and consistent performance.
  • RoHS Compliant: Environmentally friendly, these resistors meet all RoHS standards, ensuring they are free from hazardous substances.

Applications

  • Precision Instrumentation: Perfect for use in measurement and test equipment where accurate resistance values are crucial.
  • Analog Circuits: Ideal for use in analog signal processing circuits where small resistance values are needed for precise signal control.
  • Voltage Dividers: Excellent for creating precise voltage dividers where exact resistance ratios are necessary.
  • Current Sensing: Suitable for use in current sensing applications where small resistance values provide minimal voltage drop and accurate current measurement.
  • Calibration and Testing: Essential in calibration circuits and test equipment requiring high precision and stability.

Technical Specifications

  • Tolerance: ±1%
  • Resistance Range: Available from 1Ω to 150Ω
  • Power Rating: 1/4W available
  • Temperature Coefficient: ±50ppm/°C
  • Package Types: Axial, Surface Mount (SMD)
  • Material: Metal film, Carbon film options
  • Operating Temperature: -55°C to +155°C

Ordering Information

To select the appropriate resistor for your needs, please specify the resistance value, power rating, and package type. For example:

  • Product Code: R1-0.5Ω-1/4W-SMD
  • Description: 0.5 Ohm 1% Tolerance, 1/4 Watt, Surface Mount Resistor

Why Choose Our Resistors?

Our 1% Tolerance Small Value Resistors stand out due to their exceptional precision, reliability, and versatility. They are crafted to meet the high standards of modern electronic applications, ensuring your designs achieve the desired performance and stability. Whether you’re working on advanced instrumentation, sensitive analog circuits, or need precise current measurement, our resistors provide the accuracy and dependability you require.

Embrace the precision and quality of our 1% Tolerance Small Value Resistors, and ensure your electronic projects perform with unmatched reliability and accuracy.

Includes

1 Ω12 Ω27 Ω68 Ω
2.2 Ω,13 Ω33 Ω82 Ω
4.7 Ω15 Ω39 Ω120 Ω
6.8 Ω18 Ω47 Ω150 Ω
8.2 Ω22 Ω56 Ω
Small Resistance Value

1 Ω, 12 Ω, 120 Ω, 13 Ω, 15 Ω, 150 Ω, 18 Ω, 2.2 Ω, 22 Ω, 27 Ω, 33 Ω, 39 Ω, 4.7 Ω, 47 Ω, 56 Ω, 6.8 Ω, 68 Ω, 8.2 Ω, 82 Ω
