L298N Motor Driver Module Dual H-Bridge 3A

L298N Motor Driver Module Dual H-Bridge 3A – Overview

The L298N Motor Driver Module Dual H-Bridge 3A is a compact, high-performance motor driver board built around the proven L298N dual H-bridge IC. Designed for makers, students and engineers, this module can drive two DC motors independently or one bipolar stepper motor with reliable PWM speed control and direction control.

Key Benefits of the L298N Motor Driver Module

• Reliable motor control using the established L298N driver IC for stable bidirectional operation
• High current capacity – supports up to 3A continuous per channel with proper cooling
• Flexible power – wide motor voltage range of 5V to 35V for a variety of DC motors
• Easy microcontroller integration – TTL-compatible inputs work with Arduino, Raspberry Pi, ESP32 and more
• Cost-effective and easy to mount in robot chassis or prototypes

Features and Functionality

• Dual H-Bridge outputs for two independent DC motors or one bipolar stepper
• 3A per channel continuous current capability (observe heat and cooling requirements)
• Onboard 5V regulator to supply logic when using a single power source
• TTL inputs IN1-IN4 for direction control and ENA/ENB for PWM speed control
• Screw terminals and header pins for secure motor/power connections and easy prototyping
• Integrated heat sink to improve thermal dissipation under load
• Mounting holes for quick installation in chassis or enclosures

Technical Specifications

• Driver IC: L298N dual H-bridge
• Maximum current: 3A per channel (subject to heat sinking and duty cycle)
• Motor supply voltage: 5V to 35V (verify motor ratings before use)
• Logic supply voltage: 5V (onboard regulator available)
• Control pins: IN1, IN2, IN3, IN4 for direction; ENA and ENB for PWM speed control
• Connections: Screw terminals for motor and power, 2×3 header pins for signal connections
• Protection: Thermal shutdown at IC level – provide proper cooling for sustained loads
• Dimensions: Compact PCB with mounting holes – see product images or spec sheet for exact size

Common Use Cases for the L298N Motor Driver Module

• Robotics – drive wheel motors for mobile robots, line followers and autonomous platforms
• Home automation – control small conveyor systems, actuators and motorized mechanisms
• DIY prototyping – ideal for Arduino and Raspberry Pi motor projects
• Educational kits – teach H-bridge operation, PWM speed control and motor behavior
• Stepper motor control – run small bipolar steppers using appropriate stepping logic

Getting Started – Basic Hookup Guide

Follow these steps for a safe basic connection:

1. Connect the motor power supply to the motor Vcc screw terminal and ground to GND.
2. If using the onboard regulator, enable the 5V logic supply; otherwise provide a separate 5V logic supply to Vcc logic.
3. Wire motors to the output screw terminals (Motor A and Motor B).
4. Use IN1-IN4 pins to set motor direction. Use ENA and ENB with PWM signals from your microcontroller to control speed.
5. Include decoupling capacitors and ensure the power supply can handle motor stall currents and peaks.

Recommended Wiring Notes

• Use short, thick wires for motor power to reduce voltage drop.
• Place capacitors near the motor supply terminals to reduce noise and voltage spikes.
• Consider adding external flyback diodes or use motors with suppression to protect logic from noise.

Performance Tips

• Use a power supply rated above the motor stall current and provide headroom for peak draws.
• Improve cooling with additional heat sinks or fans for prolonged high-current operation.
• Test PWM frequency and duty cycle to find balance between smooth motor response and heat generation.
• Ensure proper grounding between the driver and microcontroller to avoid signal errors.

What is Included

• 1x L298N Motor Driver Module Dual H-Bridge 3A
• Documentation and basic wiring diagram (digital download or printed insert)

Order the L298N Motor Driver Module Dual H-Bridge 3A

Bring reliable, cost-effective motor control to your next project. The L298N Motor Driver Module Dual H-Bridge 3A offers flexible voltage range, PWM speed control and easy microcontroller integration. Click to purchase for full specifications, wiring diagrams and support resources.
