JST Male Connector 2.54mm (5-Pin) (Straight / Right Angle)


– JST Male Connector with 2.54mm pitch for standard PCB headers
– 5-pin configuration supports multiple signal or low-power lines
– Available in straight (vertical) and right-angle (horizontal) orientations
– Durable metal contacts and high-quality plastic housing for reliable conductivity
– Compact form factor ideal for Arduino, robotics, drones, RC models, and sensors
– Easy to solder or crimp into PCB headers, wiring harnesses, and prototyping boards

 20

Overview — JST Male Connector 2.54mm (5-Pin)

The JST Male Connector 2.54mm (5-Pin) is a compact, reliable connector designed for secure electrical connections in electronic circuits. With a 2.54mm pitch and 5-pin layout, this connector is ideal for signal routing, low-power supplies, and multi-wire connections in a wide range of projects.

Key Benefits

  • Secure mating and stable electrical contact for long-term reliability
  • Choice of straight or right-angle bodies to suit different PCB layouts
  • Durable metal contacts resist wear and corrosion for consistent conductivity
  • Compact size saves board space while supporting multiple connections

Specifications

  • Type: JST male connector
  • Pitch: 2.54mm (0.1 inch)
  • Pin count: 5 pins
  • Variants: Straight (vertical) and Right Angle (horizontal)
  • Housing: High-quality plastic
  • Contacts: Durable metal, plated for improved conductivity
  • Typical applications: Low-current signal and power connections

Variants and When to Use Them

Straight (Vertical) Version

Use the straight 5-pin JST connector when you need vertical connections from a wire harness to a PCB or when stacking boards. The straight orientation is ideal for through-board and upright pin access.

Right Angle (Horizontal) Version

The right-angle 5-pin JST connector is best for edge-mounted or space-constrained designs where horizontal cable routing is preferred. It reduces height above the PCB and keeps cables parallel to the board surface.

Applications

This connector is widely used across hobbyist and professional projects, including:

  • Arduino and microcontroller projects
  • Robotics and automation systems
  • Drones and RC models
  • Sensor modules and communication boards
  • Prototyping on breadboards and perfboards (with proper header pairing)

Installation and Compatibility Tips

  • Confirm 2.54mm pitch compatibility with your PCB footprint or header strip.
  • Use correct crimp terminals or solder to a compatible header for a secure connection.
  • When using right-angle connectors, check board clearance and cable routing before assembly.
  • Inspect contacts for proper plating and seating to prevent intermittent connections.

Package Contents

  • 1 × JST Male Connector 2.54mm (5-Pin) (Straight or Right Angle)

Why Choose This JST Male Connector?

The JST Male Connector 2.54mm (5-Pin) offers a dependable, low-cost solution for linking multiple signals or low-power lines in compact electronic designs. Its proven form factor and availability in straight and right-angle versions make it a versatile choice for hobbyists and engineers alike.

Ordering and Notes

  • Choose the straight or right-angle variant that matches your PCB layout and cable routing needs.
  • Images are for illustration purposes only; verify the orientation and pin count before installation.
