The 74386 Quad 2-Input XOR Gate IC (DIP) is a high-performance logic IC that features four independent 2-input Exclusive-OR (XOR) gates in a single package. Designed using TTL logic technology, this IC is widely used in arithmetic operations, digital logic designs, and error detection/correction applications. Each XOR gate provides an output that is HIGH when the number of HIGH inputs is odd, making it a fundamental building block in digital systems such as adders, parity generators, and comparators.
This IC comes in a DIP (Dual Inline Package), making it suitable for breadboards and through-hole PCB projects. It operates with standard TTL voltage levels and ensures reliable switching performance. With low power consumption, high noise immunity, and wide applicability in digital electronics, the 74386 IC is an essential component for students, hobbyists, and professionals working on logic circuit design.
Features:
- Contains 4 independent 2-input XOR gates
- Standard TTL logic compatibility
- DIP package for easy prototyping and soldering
- Ideal for digital arithmetic, parity checking, and logic circuits
- Wide operating voltage and stable performance
Applications:
- Digital adders and subtractors
- Error detection and parity checking circuits
- Data comparison and logic control systems
- General purpose logic circuit design
Note: Images are for Illustration Purposes Only
