7410 Triple 3-Input NAND Gate IC (DIP)

7410 Triple 3-Input NAND Gate IC (DIP) – Overview

The 7410 Triple 3-Input NAND Gate IC is a classic TTL logic device that integrates three independent NAND gates, each with three inputs, into a single DIP-14 package. This IC is widely used in digital logic design, control circuits, timing applications, and microcontroller-based systems. Its TTL compatibility, fast switching, and breadboard-friendly packaging make it a go-to choice for students, hobbyists, engineers, and industrial applications.

Key Features of the 7410 3-Input NAND Gate IC

• Three independent 3-input NAND gates in one DIP-14 package.
• TTL-compatible inputs and outputs for reliable interfacing with standard logic families.
• Wide supply voltage range: 4.75V to 5.25V (typical 5V).
• Fast typical propagation delay: 10 ns for quick logic transitions.
• Low power consumption and stable performance across temperature range.
• Breadboard and PCB friendly DIP package for rapid prototyping and assembly.

Specifications

• IC Number: 7410
• Logic Type: Triple 3-Input NAND Gate
• Number of Gates: 3
• Inputs per Gate: 3
• Operating Voltage (Vcc): 4.75V to 5.25V (Typical 5V)
• Input Current (High): 40 µA (Max)
• Input Current (Low): -1.6 mA (Max)
• Output Current (High): -0.4 mA
• Output Current (Low): 16 mA
• Propagation Delay Time: 10 ns (Typical)
• Package Type: DIP-14 (Dual Inline Package)
• Operating Temperature Range: 0°C to +70°C

Typical Logic Operation

The 7410 operates using positive logic. Each gate performs the NAND function on three inputs. The output is low only when all three inputs are high. Logic expression: Y = NOT(A AND B AND C) or Y = (A AND B AND C)’. Use these gates to implement combinational logic, control conditions, and simple arithmetic/logic blocks.

Applications

• Digital logic circuit design and development
• Timing and control systems
• Arithmetic and logic operations in combinational circuits
• Signal processing and logic control modules
• Educational and training kits for learning TTL logic
• Embedded systems and microcontroller projects requiring hardware logic

Package, Mounting and Prototyping

The DIP-14 package of the 7410 makes it easy to insert into breadboards and through-hole PCBs for rapid prototyping and soldered designs. Its robust TTL characteristics ensure predictable behavior when interfaced with other 74xx family devices and many microcontrollers through proper level considerations.

Why Choose the 7410 for Your Project

• Consolidates multiple 3-input NAND functions into one chip, saving board space.
• Reliable TTL performance for vintage and modern digital systems.
• Fast switching suitable for many timing-sensitive applications.
• Widely available and well documented, making it ideal for education and prototyping.

Note: Images are for illustration purposes only.
