Overview: Ultrasonic Sensor Acrylic Mounting Bracket
The Ultrasonic Sensor Acrylic Mounting Bracket is a robust and precise mounting solution designed to secure ultrasonic sensors such as the GY-273 and similar modules. Made from high-quality acrylic, this bracket provides stable alignment and low weight, helping improve measurement accuracy in robotics, automation, and prototyping projects.
Key Features of This Ultrasonic Sensor Mount
- Durable acrylic material: Lightweight yet strong acrylic for long-lasting performance.
- Precision fit: Engineered to align ultrasonic sensors accurately, minimizing measurement error.
- Easy installation: Pre-drilled holes and a straightforward design let you mount sensors quickly.
- Vibration reduction: Secure mounting reduces movement that can affect readings.
- Versatile: Suitable for robotics, distance measurement systems, automation, and prototyping.
Why material and design matter
Acrylic offers a balance of rigidity and lightness. The bracket’s cut and hole placement prioritize sensor alignment and practical mounting on frames, chassis, and panels commonly used in electronic and robotic builds.
Installation Guide: Mounting Your Ultrasonic Sensor
- Align the sensor with the bracket so the transducers face the intended detection direction.
- Use the pre-drilled holes to secure the sensor with appropriate screws or standoffs.
- Fasten the bracket to your project frame, ensuring the mount is flush and stable.
- Verify alignment by running a quick distance check to confirm consistent readings.
Applications: Where to Use This Acrylic Bracket
- Robotics: Reliable mounting for navigation and obstacle avoidance sensors.
- Distance measurement: Stable sensor placement for accurate range sensing.
- Prototyping and education: Handy solution for student projects and makers.
- Automation systems: Integrate into monitoring and control systems that depend on ultrasonic feedback.
Compatibility and Best Practices
This bracket is compatible with common ultrasonic sensor modules such as the GY-273 and other similarly sized sensors. For best results, match screw sizes and standoff heights to your specific sensor and housing. Ensure the transducers have an unobstructed path to the target surface for optimal performance.
Maintenance and Care
- Keep the bracket clean and free of dust or adhesive residue that could block transducers.
- Inspect mounting screws periodically to maintain a vibration-free attachment.
- Avoid prolonged exposure to direct sunlight to reduce long-term UV yellowing of acrylic.
Order from Colgroad in Pakistan
Buy the Ultrasonic Sensor Acrylic Mounting Bracket from Colgroad for a reliable and fast delivery across Pakistan. Whether you are a hobbyist, student, or professional, this mount helps you achieve precise sensor alignment and consistent measurements.
Get Started
Order your Ultrasonic Sensor Acrylic Mounting Bracket today and improve the stability and accuracy of your ultrasonic sensor projects. If you need help confirming compatibility with your sensor module, contact Colgroad support for guidance.
