T-M274 Radar DIY Learning Kit

Overview

The T-M274 Radar DIY Learning Kit is a hands-on educational project that teaches the fundamentals of radar technology, ultrasonic sensing, and distance measurement. Learners assemble an Arduino-compatible radar system that scans 0 to 180 degrees using a servo-mounted ultrasonic sensor and visualizes detected object position and distance in real time. This kit is ideal for classroom STEM activities, maker workshops, and hobbyist experimentation.

Key Features & Highlights

• Working radar model using ultrasonic waves to detect nearby objects
• STEM learning kit that teaches radar concepts, sensor operation, and data visualization
• Hands-on assembly experience to explore electronics, wiring, and basic coding
• Real-time detection displays measured distance and scanning angle
• Durable construction with acrylic or wooden base and quality electronic parts

Package Includes

• Connecting wires set
• Radar base frame (acrylic or wooden)
• Instruction manual with assembly and programming guidance

Specifications

• Operating voltage: 5V DC
• Control board: Arduino-compatible microcontroller
• Sensor type: Ultrasonic distance sensor
• Servo scanning range: 0 to 180 degrees
• Detection range: Up to 4 meters (approximate)
• Material: Acrylic or wood plus electronic components
• Assembly time: 60-90 minutes
• Skill level: Intermediate (basic coding and wiring skills recommended)

Educational Value and Learning Outcomes

• Understand how radar and sonar systems detect objects using sound waves
• Learn how sensors, servos, and microcontrollers work together to collect and display data
• Develop circuit design, wiring, and Arduino programming skills
• Improve problem-solving, logical reasoning, and experimental measurement techniques

Applications and Use Cases

• Classroom STEM projects and demonstrations
• Maker spaces and robotics clubs for prototyping sensing systems
• Hobbyist projects requiring non-contact distance measurement and scanning
• Introductory lessons in signal detection and data visualization

Assembly and Quick Start

1. Unpack components and review the instruction manual.
2. Mount the ultrasonic sensor to the servo and attach the assembly to the base frame.
3. Connect the wiring to the Arduino-compatible control board following the schematic in the manual.
4. Upload the provided example Arduino sketch to test servo scanning and distance readings.
5. Adjust visualization parameters and explore different scanning speeds and sample rates.

Tips and Compatibility

• Requires a USB cable or 5V power supply for the control board.
• Works with standard Arduino IDE; example code is included for quick setup.
• Test in open areas for best ultrasonic sensor performance; reflective objects provide stronger returns.
• Recommended for learners with basic soldering and wiring experience or teacher supervision for beginners.

Frequently Asked Questions

• Can this kit be expanded for robotics projects? Yes. The Arduino-compatible control board and ultrasonic sensor are commonly used in robotics and can be integrated into larger systems.
• Is programming experience required? Basic coding skills are helpful. The kit includes example code and comments to guide learners through modification and experimentation.
• Are images included? Note: Images are for illustration purposes only.

The T-M274 Radar DIY Learning Kit provides a practical, engaging introduction to sensing and measurement technologies, perfect for classrooms and makers. It combines mechanical assembly, electronics, and coding to create a real-time radar visualization platform suitable for a wide range of educational projects.
