Small Limit Switch

Availability:

Available on backorder


  • Compact snap-action limit switch for tight spaces
  • Precision lever actuator for accurate position detection
  • 3-pin terminals (COM, NO, NC) for flexible wiring
  • Easy screw-hole mounting for secure installation
  • Ideal for robotics, CNC machines, and 3D printers
  • Durable construction for long service life in low-voltage circuits

Product Overview

The Small Limit Switch is a compact, high-precision mechanical switch designed for reliable position detection and end-stop applications. Featuring a durable lever actuator and a snap-action mechanism, this switch delivers fast, repeatable switching ideal for automation, CNC machines, robotics, 3D printers, and hobby electronics.

Why Choose This Small Limit Switch

  • Compact form factor makes it easy to integrate into tight spaces and small enclosures.
  • Snap-action mechanism provides quick and reliable transitions for accurate limit detection.
  • Lever actuator offers precise actuation and long-term durability under repeated cycles.
  • Versatile 3-pin wiring (COM, NO, NC) supports both normally open and normally closed configurations.

Key Features

  • Compact and lightweight design for space-constrained installations
  • Snap-action mechanism for rapid response and consistent actuation
  • Durable lever actuator built for repeated mechanical cycling
  • 3-pin terminals: COM, NO, NC for flexible wiring options
  • Easy installation with screw holes for secure mounting
  • Suitable for low-voltage, low-current circuits in control and sensing roles

Specifications

  • Switch Type: Mechanical limit switch
  • Terminals: 3-pin (COM, NO, NC)
  • Actuator: Lever type
  • Mounting: Screw holes for easy fixing
  • Size: Small and compact
  • Rated Voltage/Current: Typically 250V AC / 5A (varies by model)

Wiring and Mounting Guidelines

  • Identify COM, NO, and NC pins before wiring. COM to supply, NO for circuit that closes on actuation, NC for circuit that opens on actuation.
  • Use appropriate gauge wire and secure terminals to prevent intermittent connections.
  • Mount the switch using the provided screw holes. Ensure the lever and actuator path are unobstructed for reliable operation.
  • For safety interlocks and motor end-stops, confirm wiring and test switching action at low power before full operation.

Typical Applications

  • End-stops and homing switches for CNC machines and 3D printers
  • Limit detection in robotic arms and articulated mechanisms
  • Safety interlocks and motor cutoff switches
  • Position sensing in automation systems and DIY electronics projects

Installation Tips

  • Mount the switch on a stable surface to avoid vibration-induced false triggers.
  • Adjust lever contact position to ensure consistent actuation and avoid mechanical over-travel.
  • For long-term reliability, keep the contact area free of debris and verify operation periodically.

What You Get

  • Small Limit Switch (single unit) with lever actuator
  • 3-pin terminal access and mounting holes
  • Product documentation and wiring guidance
