Servo CCPM Consistency Tester — Reliable CCPM Servo Checks for RC and Robotics
The Servo CCPM Consistency Tester is a compact, easy-to-use tool designed to test and verify the performance of servos used in Collective Pitch Control Mixing (CCPM) systems and other multi-servo applications. Ideal for RC helicopters, airplanes, boats, cars, and robotics, this three-channel tester helps you identify inconsistent or failing servos before they cause problems in the field.
Key Features
- Three testing modes — Manual (user-controlled movement), Neutral (centers all servos), and Automatic (continuous sweep to reveal inconsistencies).
- Three channels — Test up to three servos or ESCs at once for quick CCPM synchronization checks.
- Wide compatibility — Works with most analog and digital servos as well as standard ESCs.
- Compact and portable — Lightweight design fits in your toolkit for bench tests or field troubleshooting.
- User-friendly — Simple connections and an intuitive mode switch let both beginners and pros run tests fast.
Specifications
- Input Voltage: 4.8V — 6V
- Output Channels: 3 (three simultaneous servo/ESC ports)
- Modes: Manual, Neutral, Automatic
- Size & Weight: Compact, lightweight and portable
Why Use a CCPM Servo Tester?
CCPM helicopter systems and other multi-servo setups depend on precise, synchronized servo movement. A single inconsistent servo can cause poor control response, vibration, or loss of stability. The Servo CCPM Consistency Tester helps you:
- Detect dead spots, jitter, or slow/lagging servos
- Verify neutral centering for accurate CCPM mixing
- Compare analog vs. digital servo behavior quickly
- Pre-check servos and ESCs before installation or flight
Typical Applications
- RC Helicopters & Airplanes: Confirm CCPM servo synchronization for stable, predictable flight.
- RC Cars & Boats: Test steering and throttle servos/ESCs for reliable operation.
- Robotics: Validate servo responsiveness and repeatability in multi-servo mechanisms.
How to Use
- Connect a suitable power source (4.8V–6V) to the tester.
- Plug up to three servos or ESCs into the output channels.
- Select the desired mode: Manual to jog servos, Neutral to center, or Automatic to sweep.
- Observe servo movement for jitter, lag, or inconsistent travel; swap test servos to isolate issues.
Tips & Best Practices
- Use known-good servos as a baseline when diagnosing issues.
- Check connectors and wiring if a channel shows no output.
- Test servos at the voltage they will be used in the model for the most accurate results.
Package & Warranty
Package contents typically include the Servo CCPM Consistency Tester unit and basic documentation. Images are for illustration; actual product appearance may vary. Check with your supplier for warranty and support details.
The Servo CCPM Consistency Tester is an essential tool for anyone working with CCPM systems or multi-servo assemblies. Whether you are a hobbyist tuning your first helicopter or a professional maintaining a fleet, this tester saves time and reduces the risk of servo-related failures.
