Overview
The Raspberry Pi 5 Model B (4GB RAM) is the most powerful Raspberry Pi single-board computer, delivering significant performance gains for hobbyists, educators, developers, and professionals. Built around a 2.4GHz quad-core 64-bit Arm Cortex-A76 processor and 4GB of LPDDR4X-4267 RAM, the Pi 5 is engineered for demanding applications including AI, robotics, media, and dual-display desktop computing.
Key Features
- High-performance CPU: Broadcom BCM2712 2.4GHz quad-core Cortex-A76 for smooth multitasking and faster compute workloads.
- Memory: 4GB LPDDR4X-4267 SDRAM for responsive performance with modern applications.
- Advanced GPU: VideoCore VII supporting dual 4Kp60 HDMI output and hardware-accelerated video decoding for media and display-heavy projects.
- Connectivity: Dual-band Wi-Fi 802.11ac, Bluetooth 5.0, Gigabit Ethernet, and PoE+ support with a compatible HAT.
- USB and Expansion: 2 x USB 3.0 ports, 2 x USB 2.0 ports, PCIe 2.0 interface for NVMe (with adapter), and a 40-pin GPIO header fully compatible with Raspberry Pi 4 accessories.
- Camera and Display Support: Two 4-lane MIPI connectors for cameras and displays plus two micro-HDMI ports for dual 4K displays.
- Power: USB-C power input supporting 5V/5A supply for power-hungry add-ons.
Technical Specifications
- Model: Raspberry Pi 5 Model B
- Processor: Broadcom BCM2712, 2.4GHz quad-core Cortex-A76
- RAM: 4GB LPDDR4X-4267
- Graphics: VideoCore VII GPU, dual 4Kp60 HDMI output
- Storage Options: microSD card slot (UHS-I), PCIe 2.0 for NVMe with adapter
- I/O Expansion: 40-pin GPIO header, PCIe interface, 2 x 4-lane MIPI connectors
- USB: 2 x USB 3.0, 2 x USB 2.0
- Networking: Gigabit Ethernet, Wi-Fi 802.11ac dual-band, Bluetooth 5.0
- Power Supply: USB-C, supports 5V/5A
- Dimensions: 85 mm x 56 mm x 18 mm
- Weight: Approximately 40 g
- Operating Systems: Raspberry Pi OS, Ubuntu, and other supported Linux distributions
Performance and Use Cases
The Raspberry Pi 5 provides up to 2 to 3 times the performance of previous generations, making it suitable for a wide range of projects and deployments:
- AI inference and edge machine learning workloads
- Robotics control systems and advanced IoT gateways
- High-definition media centers, streaming devices, and retro gaming consoles
- Dual-display desktop setups for productivity and kiosk systems
- STEM education, programming, and prototyping in classrooms and labs
- Industrial automation and embedded solutions requiring compact compute
Expansion, Storage and Connectivity Tips
- Use a UHS-I microSD card for the best boot and application performance without additional hardware.
- For high-speed storage and faster I/O, attach an M.2 NVMe drive via a PCIe adapter to leverage the Pi 5s PCIe 2.0 lane.
- Take advantage of USB 3.0 ports for external drives and peripherals that require higher throughput.
- Enable PoE+ with a compatible HAT for remote or mounted installations where power-over-Ethernet is required.
GPIO, Cameras and Displays
The 40-pin GPIO header maintains backward compatibility with Raspberry Pi 4 HATs and accessories. Two 4-lane MIPI connectors support modern camera modules and official displays, enabling advanced vision and UI projects.
Why Choose Raspberry Pi 5 Model B 4GB
- Best-in-class price to performance for single-board computing
- Flexible expandability with PCIe, USB 3.0, and robust networking
- Well-supported software ecosystem including Raspberry Pi OS and Ubuntu
- Compact form factor suitable for both desktop and embedded use
Applications
Ideal for DIY electronics, robotics, IoT systems, AI and machine learning projects, media centers, retro gaming consoles, education, industrial prototyping, and dual-display desktops.
What is Included
- Raspberry Pi 5 Model B board with 4GB LPDDR4X RAM
- Documentation and links to official images and software
- Note: Power supply, microSD card, NVMe adapter and peripherals are sold separately
Note: Images are for Illustration Purposes Only.
