Lithium Battery Fast Charging Module 3A (IP2312)

Product Overview: Lithium Battery Fast Charging Module 3A (IP2312)

The Lithium Battery Fast Charging Module 3A (IP2312) is a compact, high-efficiency charging solution for single-cell lithium-ion and lithium-polymer (LiPo) batteries. Using the IP2312 charging controller, the module supports fast charging up to 3A with reliable constant-current / constant-voltage (CC/CV) management and automatic recharge.

Why choose the IP2312 3A charging module

• Fast charging performance for quicker battery top-ups and reduced downtime
• Intelligent charge management that optimizes battery life and safety
• Small footprint for easy integration into DIY electronics, portable devices, and embedded systems

Key Features

• IC Used: IP2312 fast charging controller
• Maximum Charging Current: Up to 3A (supports fast charging)
• Battery Support: Single-cell Li-ion / LiPo batteries
• Charging Method: Constant Current / Constant Voltage (CC/CV)
• Protections: Overvoltage protection, overcurrent protection, thermal protection
• Input Voltage: Typically 5V DC (USB or adapter)
• Form Factor: Compact, low-profile board easy to mount in small enclosures

Technical Specifications

• Charging controller: IP2312
• Input: 5V DC (USB) typical; check module markings for alternative input ranges
• Output: Single-cell charge output up to 3A
• Charging algorithm: CC/CV with automatic termination and recharge
• Operating temperature: Refer to IP2312 datasheet for thermal limits; module includes thermal protection
• Size: Compact PCB for space-constrained applications

Protections and Safety

• Overvoltage protection prevents battery overcharging
• Overcurrent protection limits charging current to protect battery and circuit
• Thermal protection reduces charge or shuts down when the module overheats
• Automatic recharge restarts charging when battery voltage falls below a threshold

Typical Applications

• Power banks and portable battery packs
• Battery management and charging circuits for single-cell devices
• Robotics, drones, and remote-controlled devices
• IoT devices and energy storage modules
• DIY electronics and hobbyist projects that require fast, safe charging

Integration and Wiring Tips

• Use a stable 5V DC supply (USB or adapter) capable of delivering the desired charging current plus margin.
• Place the module away from heat sources and allow airflow for best thermal performance.
• Route battery and input wires carefully to minimize voltage drop; use thicker wires for higher currents up to 3A.
• Verify polarity before connecting the battery to avoid damage to the module and battery.
• Consult the IP2312 datasheet for exact pinout and recommended external components when designing into a custom PCB.

What’s in the Box

• Lithium Battery Fast Charging Module 3A (IP2312) PCB
• Basic product label and wiring markings on the module

Note: Images are for Illustration Purposes Only.
