IC Base 8/14/16/20/40 Pins

IC Base 8 Pin – Precision Socket for Secure Chip Mounting

The IC base 8 pin provides a clean, reliable, and replaceable connection for 8-pin dual in-line package (DIP) chips. Designed for hobbyists, engineers, and technicians, this socket keeps IC legs safe during soldering and makes repair and prototyping work fast and efficient.

Key Features

• Designed for 8-pin DIP chips; also available in 14, 16, 20, and 40 pin variants
• Fits standard PCB drill holes and breadboards with a snug, secure fit
• High-quality metal contacts for excellent electrical conductivity
• Heat-resistant plastic housing tolerates multiple soldering cycles
• Reusable design enables easy replacement and safe chip removal

Materials and Durability

This IC socket combines a heat-resistant thermoplastic body with copper alloy contacts to ensure long-lasting performance. The resilient contacts provide a firm grip on IC pins without causing deformation or introducing extra thermal stress during soldering.

Compatibility and Typical Use Cases

• Compatible with common 8-pin ICs such as op-amps, timers, EEPROMs, and small microcontrollers
• Ideal for PCB assembly, prototyping, classroom labs, and electronics repair
• Works with breadboards for quick testing and circuit iteration

Installation and Best Practices

• Place the socket flush with the PCB and solder each pin for a reliable connection
• Use moderate soldering temperature and quick contact to avoid overheating the plastic body
• When inserting ICs, align pins carefully and press straight down to prevent bent leads
• For frequent swapping, inspect contacts periodically for wear and replace the socket if contact resistance increases

Technical Specifications

• Pin counts available: 8, 14, 16, 20, 40
• Package type: Dual In-line Package (DIP)
• Pin pitch: Standard 2.54 mm (0.1 inch)
• Materials: Heat-resistant thermoplastic body, copper alloy contacts
• Mounting: Through-hole for PCBs and breadboards

Why Choose This IC Base

Protect your ICs and speed up development with a socket that reduces rework and preserves component integrity. Whether you are building prototypes, repairing circuits, or teaching electronics fundamentals, this IC base delivers dependable performance and easy maintenance.

Order Now – Upgrade Your PCB Assembly

Add the IC base 8 pin to your toolkit for reliable, easy, and reusable IC mounting that lasts. Save time, protect components, and simplify testing with a quality DIP socket designed for real-world electronics work.
