BF350-3AA Strain Gauge Resistive Pressure Sensor

Availability:

In stock


resistive strain gauge sensor with a 350 ohm nominal resistance which varies when a force is applied. By measuring the change in the sensors resistance a measurement of the force applied to it can be obtained. Note that strain gauges exhibit small changes in resistance and so this sensor should be used in a Wheatstone bridge configuration. If using with a microcontroller such as an Arduino we also recommend using our HX711 digital bridge sensor interface module.

Features:

  • Nominal resistance(Ohm): 350
  • Tolerance: <±0.1%
  • Gauge factor: 2.00~2.20
  • Gauge factor resistance: <±1%
  • Strain limit: 2.0%
  • Fatigue life: >10
  • Metal foil: constantan alloy
  • Working temperature range: -30~+80℃
  • Temperature compensation: Aluminium(23)
  • Gauge Grid(mm) Dimensions(L×M): 3.2 x 3.06
  • Gauge Creep Code: M6 to O6

Application



90.00

In stock

resistive strain gauge sensor with a 350 ohm nominal resistance which varies when a force is applied. By measuring the change in the sensors resistance a measurement of the force applied to it can be obtained. Note that strain gauges exhibit small changes in resistance and so this sensor should be used in a Wheatstone bridge configuration. If using with a microcontroller such as an Arduino we also recommend using our HX711 digital bridge sensor interface module.

Features:

  • Nominal resistance(Ohm): 350
  • Tolerance: <±0.1%
  • Gauge factor: 2.00~2.20
  • Gauge factor resistance: <±1%
  • Strain limit: 2.0%
  • Fatigue life: >10
  • Metal foil: constantan alloy
  • Working temperature range: -30~+80℃
  • Temperature compensation: Aluminium(23)
  • Gauge Grid(mm) Dimensions(L×M): 3.2 x 3.06
  • Gauge Creep Code: M6 to O6

Application
