Arduino MEGA Proto Shield Module with Mini Breadboard

Arduino MEGA Proto Shield Module with Mini Breadboard

The Arduino MEGA Proto Shield Module with Mini Breadboard is a convenient prototyping shield designed for the Arduino MEGA 2560. It speeds up circuit testing and development by providing a removable mini breadboard plus solderable pads so you can prototype quickly and create permanent solutions when needed.

Key Features

• Compatibility with Arduino MEGA 2560: plugs directly into MEGA headers and breaks out all I/O pins.
• Removable mini breadboard: rapid, solderless prototyping for sensors, modules and ICs.
• Soldering pads and headers: create permanent circuits once your design is finalized.
• Onboard reset button: convenient resetting without reaching the main board.
• Power indicator LED: quick visual confirmation of board power status.
• Compact and reusable: ideal for classrooms, makerspaces and hobby benches.

Compatibility and Connectivity

This proto shield is made especially for the Arduino MEGA 2560. It breaks out all MEGA I/O pins to accessible headers so you can connect sensors, displays, communication modules and custom circuits without soldering to the main board.

Applications

• Rapid prototyping of circuits and sensor integrations using the mini breadboard.
• Testing and breadboarding ICs, modules and custom circuits before final soldering.
• Educational projects and hands-on electronics learning for students.
• DIY electronics, robotics and hobbyist projects that require quick iteration.
• Transitioning designs from breadboard to permanent soldered circuits using the shield pads.

How to Use

1. Insert the shield onto the Arduino MEGA 2560 headers, aligning pins carefully.
2. Place components and jumpers on the removable mini breadboard to test connections.
3. Use the breakout headers for direct wiring to modules or sensors.
4. Once tested, solder components to the provided pads for a permanent build.
5. Use the onboard reset button and monitor the power LED to check status during testing.

Why Choose This Proto Shield

• Saves time: removable breadboard accelerates the prototyping cycle.
• Safe for beginners: avoid soldering directly to the Arduino while learning.
• Flexible: switch between temporary breadboarding and permanent soldered solutions.
• Compact design: fits neatly on the MEGA for bench and classroom use.

Technical Details

• Board type: Proto shield compatible with Arduino MEGA 2560.
• Breadboard: Removable mini breadboard, standard tie-point layout.
• Prototyping: Solderable pads and header breakouts for all MEGA pins.
• Controls and indicators: Onboard reset button and power indicator LED.

Package Contents

• 1 x Arduino MEGA Proto Shield Module
• 1 x Removable mini breadboard

Note: Images are for Illustration Purposes Only.
