8-Way Dip Switch SPST Slide Switch (2.54mm)

8-Way DIP Switch SPST Slide Switch (2.54mm) Overview

The 8-Way DIP Switch SPST Slide Switch (2.54mm) is a compact, reliable configuration component for digital electronics, embedded systems, and prototyping. It contains eight independent Single Pole Single Throw (SPST) slide switches in a dual in-line (DIP) package. With a standard 2.54mm pitch, it installs easily on breadboards, prototyping boards, and PCBs for quick hardware configuration without soldering.

Key Features

• 8 independent SPST switches in one DIP module for binary or multi-flag configurations
• Standard 2.54mm pin spacing for universal compatibility with breadboards and PCBs
• Gold-plated contacts for reliable conductivity and reduced oxidation
• Positive tactile sliding action with clear ON/OFF marking for each switch
• Durable plastic enclosure with through-hole terminals for secure mounting
• Compact footprint ideal for microcontrollers, logic circuits, and test rigs

Specifications

• Type: DIP slide switch
• Number of switches: 8
• Switch type: SPST (Single Pole Single Throw)
• Pitch: 2.54mm
• Contact resistance: 3c= 50m9
• Insulation resistance: 3e= 100M9
• Dielectric strength: 500V AC/min
• Rated voltage: Up to 24V DC
• Rated current: 25mA (typical)
• Operating temperature: -20DA to +85DAC
• Mechanical life: 2000+ cycles per switch
• Mounting type: Through-hole
• Material: Plastic body with gold-plated terminals

Applications

• Microcontroller boards (Arduino, Raspberry Pi, ESP32) for address and mode selection
• Digital logic circuits and programmable systems configuration
• Embedded system design for parameter and control line setup
• Communication systems for ID, channel, or address configuration
• Test benches and prototyping for debugging and signal routing
• Industrial control systems requiring manual logic selection

Mounting, Compatibility, and Usage Tips

• Fits breadboards and 0.1 inch (2.54mm) header layouts for rapid prototyping
• Use as binary address switches for DIP-configured devices or to set operation modes
• For reliable long-term performance, clean mating pads and avoid excessive mechanical stress
• Verify rated voltage/current limits (24V DC, 25mA typical) for your use case
• If using in high-reliability systems, consider redundant logic or supervision of switch states

Why Choose This 8-Way DIP Switch

This 8-Way DIP SPST slide switch delivers a balance of compact size, robust contacts, and straightforward operation. It is ideal for engineers, students, and hobbyists who need quick, repeatable hardware configuration without adding complex circuitry. The gold-plated terminals and durable body provide dependable performance across many prototyping and low-power production applications.

Note

Images are for illustration purposes only. Check the product datasheet or contact the seller for detailed mechanical drawings and exact part variations before finalizing your design.
