Overview
The 4.3 Inch DWIN HMI Capacitive Touch LCD Module (DMG48270C043_04WTC) is a compact, commercial-grade display designed to bring reliable, high-quality touch interfaces to industrial, embedded, and home automation systems. With a native 480×272 resolution and a capacitive touch panel, this DWIN touch LCD module balances clarity, responsiveness, and durability for demanding applications.
Key Features
- Model: DMG48270C043_04WTC
- Display size: 4.3 inch
- Resolution: 480 x 272 pixels for sharp visuals and readable UI
- Capacitive touch panel for fast, accurate touch response
- Commercial-grade build for long-term reliability in industrial environments
- DGUS II HMI Display support for easy GUI design and customization
- UART interface compatibility for straightforward integration with microcontrollers and PLCs, including local use in Pakistan
Technical Specifications
- Active area: optimized for 4.3 inch HMI projects
- Pixel arrangement: 480 x 272 (W x H)
- Touch type: Capacitive touch, multi-touch capable depending on controller
- Interface: UART communication for commands, data transfer, and firmware updates
- Supported firmware: DGUS II HMI system for rapid GUI development
- Operating temperature: designed for commercial environments
Integration and Compatibility
This DWIN HMI LCD Module is engineered for easy integration. The built-in UART compatibility simplifies wiring to popular microcontrollers, PLCs, and embedded boards. DGUS II support lets developers and integrators create custom screens, animations, and control logic without deep low-level programming.
Why DGUS II Matters
- Rapid GUI development with visual tools
- Template-driven workflows to shorten project time
- Easy asset management for icons, fonts, and layouts
Ideal Applications
- Industrial control panels and machine HMIs
- Embedded products and custom electronics
- Home automation control interfaces
- Prototyping, developer platforms, and hobbyist projects
Why Choose the 4.3 Inch DWIN HMI Capacitive Touch LCD Module
This module offers a strong combination of usability and performance. The 480×272 HMI LCD Module resolution delivers sharp UI elements while the capacitive touch interface ensures modern responsiveness. Commercial-grade construction makes it a dependable choice for long-term deployments, and DGUS II plus UART compatibility ensure the display can be customized and integrated quickly.
Installation Tips
- Confirm UART voltage levels and use a level shifter if needed to protect the module and host controller.
- Use the DGUS II toolset to prepare screen assets and test the GUI before full deployment.
- Mount the module in an enclosure that allows appropriate ventilation for continuous operation.
Ordering and Support
Order the 4.3 Inch DWIN HMI Capacitive Touch LCD Module DMG48270C043_04WTC to upgrade your next project with a reliable, easy-to-integrate display. If you need technical assistance, check DGUS II documentation and manufacturer resources for firmware and GUI templates.
Note: Images are for illustration purposes only.
