The 125KHz RFID Card Reader Module JT308 is a versatile device used for reading and decoding RFID (Radio Frequency Identification) cards and tags operating at 125 kHz frequency. It is commonly utilized in access control systems, security systems, attendance systems, and various other applications requiring identification and authentication through RFID technology.
Key Features
- RFID Card Compatibility: Compatible with EM4100 series RFID cards and tags.
- Operating Frequency: Operates at 125 kHz frequency.
- Read Range: Typically reads RFID cards/tags from a distance of up to 10 cm.
- Output Format: Outputs data in a standard Wiegand 26-bit format.
- LED Indicators: Provides visual feedback for power and card reading status.
- Built-in Antenna: Integrated antenna for reliable RFID signal reception.
- Simple Interface: Easy to interface with microcontrollers or access control systems.
- Low Power Consumption: Suitable for battery-powered applications.
Applications
- Access Control Systems: Used for secure access and entry management.
- Attendance Systems: Tracks attendance and movement of personnel.
- Security Systems: Integrates into security setups for identification purposes.
- Inventory Management: Tracks and manages inventory with RFID tags.
- Automation: Used in automated systems for identification and authentication.
- DIY Projects: Popular among hobbyists for creating custom RFID-based projects.
Technical Specifications
- Operating Voltage: Typically operates at 5V DC (via microcontroller or external power supply).
- Current Consumption: Low power consumption, suitable for continuous operation.
- Interface: Wiegand 26-bit output format, compatible with most access control systems.
- Dimensions: Compact size for easy integration into various projects.
- Operating Temperature: Suitable for operation in typical indoor environments.
Benefits
- Reliable Performance: Ensures accurate and consistent RFID card reading.
- Versatile Integration: Easy integration into existing access control or security systems.
- Cost-Effective: Affordable solution for RFID-based identification and authentication.
- User-Friendly: Simple interface and LED indicators for ease of use.
- Wide Compatibility: Works with EM4100 series RFID cards/tags, widely available and supported.
How to Use
- Power Supply: Connect the module to a 5V power source.
- Antenna Placement: Ensure the RFID cards/tags are within the reading range.
- Data Output: Receive the card data in Wiegand 26-bit format.
- Integration: Interface with your microcontroller or access control system.
- Testing: Verify functionality by testing with RFID cards/tags.
Why Choose 125KHz RFID Card Reader Module JT308?
The JT308 RFID Card Reader Module offers reliable performance, wide compatibility, and ease of integration for various RFID-based applications. Whether for access control, attendance tracking, or DIY projects, it provides a cost-effective solution with robust features and functionalities.
Enhance security and streamline access control with the 125KHz RFID Card Reader Module JT308. Perfect for integrating RFID technology into your projects and systems.
